Product Details

General

VK series power supply is single channel output ,High accuracy ,dual LED display .It is continuously adjustable within the rated AC/DC. CV/CC working pattern switch automatically .Full protecting makes it safe to use : over-load protection function.,overheated protection function,short circuit protection function.With the specification of small body ,easy handling, a sturdy case, novel appearance ,good performance, excellent cost effectiveness, It is the ideal power supply unit for science investigation, college, factory, electronic appliance maintenance and etc.

Specifications

Ø Single-channel output

Ø CC/CV auto switchable

Ø 110V/220V Switchable

Ø Over-load protection function.

Ø Overheated protection function.

Ø short circuit protection function.

Ø Coarse/ fine tune the Voltage and Current

Ø Nice cooling with temperature-controlled fan

Ø 3/4 digital LED-display for voltage and current•

Ø Small body, light weight ,only 1.4KG ,easy for carry

Ø Good performance with excellent cost effective

Technical indicators

Input voltage	AC 110V/220V,50/60Hz
Output voltage	0 ~ Nominal value
Output current	0 ~ Nominal value
Voltage resolution	10/100mV
Current resolution	1/10mA
Power effect	CV≤1%+10mV
Effect of load	CV≤1%+10mV
Ripple and noise	Vp-p≤1%
Voltage display precision	±1%+1digits
Current display precision	±1%+2digits
Net/gross Weight (KG)	1.4KG /1.7KG
Dimension (mm)	81W×165H×220L
Package	8pcs/conton
